| DESCRIPCION |
MARCA |
ASUS |
| MODELO |
TUF GAMING X570 PLUS |
| CHIPSET |
AMD X570 |
| TIPO DE SOCKET |
AM4 AMD
|
| PROCESADORES |
COMPATIBLE |
Procesador AMD Ryzen 3 SAM4 2XXX
Procesador AMD Ryzen 5 SAM4 3XXX
|
| MEMORIAS |
SOPORTA |
Memoria RAM DDR4 2400Mhz PC4-19200
Memoria RAM DDR4 2666Mhz PC4-21300
Memoria RAM DDR4 3000Mhz PC4-24000
Memoria RAM DDR4 3200Mhz PC4-25600
Memoria RAM DDR4 3600Mhz PC4-28800
|
| TIPO |
DDR4 |
| NUMERO DE RANURAS |
4 |
| EXPANSION MAXIMA |
128 GB |
| TECNOLOGIA |
DUAL CHANNEL
|
| NOTA |
SOPORTA MEMORIA UN BUFFERED MEMORY |
| SONIDO |
CHIPSET |
REALTEK® ALC1200 |
| CANALES |
8 |
| CONECTIVIDAD |
LAN |
CHIPSET |
REALTEK® L8200A |
| VELOCIDAD |
10/100/1000 MB/S |
| CONECTOR PARA FUENTE |
ATX 12V 24 PINES
ATX 12V 2x2 PINES
ATX 12V 4x2 PINES
|
| CONTROLADORES DE ALMACENAMIENTO |
SERIAL ATA |
NUMERO DE CONTROLADORES 6GB/S |
8 |
| CONECTOR M.2 |
SOCKET 3 |
1 x M KEY (TIPO 2242/2260/2280/22110)
1 x M KEY (TIPO 2242/2260/2280/22110) |
| SOPORTA RAID |
RAID 0
RAID 1
RAID 10
|
| DISPONE DE SLOTS |
PCI EXPRESS 3.0 X16 |
1 |
| NOTA |
1 x PCIe 4.0 x16
3 x PCIe 4.0 x1 |
| PUERTOS INTERNOS |
USB 2.0 / 1.1 INTERNO |
2 |
| TRUSTED PLATFORM MODULE |
| CONECTORES BACK PANEL |
PS/2 COMBO |
1 |
| HDMI |
1 |
| DISPLAY PORT |
1 |
| RJ-45 |
1 |
| LINE-IN |
1 |
| LINE-OUT |
1 |
| MICROFONO |
1 |
| CENTER/SUBWOOFER OUT |
1 |
| REAR SPEAKER OUT |
1 |
| OPTICAL S/PDIF OUT |
1 |
4 x USB 3.2 GEN 2
3 x USB 3.2 GEN 2 - (hasta 10 Gbps) puertos (TIPO-A + USB TIPO-C) |
| MARCA DE BIOS |
AMI BIOS UEFI |
| FACTOR DE FORMA |
TIPO |
ATX |
| ANCHO |
30.50 CM |
| LARGO |
24.40 CM |
| PRESENTACION |
CAJA
|
|
Motherboard Asus TUF Gaming X570 Plus, AM4, X570, DDR4, SATA 6.0, USB 3.2.
Soporta procesadores 2da y 3ra generación Ryzen, 4 ranuras DDR4 2133/2400/2666/2800/3000/3200/3400/3600 MHz, LAN Realtek L8200A GbE, SN/VD/NW, formato ATX.
